MA-ANT-3-D5 Meraki Indoor Dual-band Downtilt Omni Antenna 5port (MR42E).

Cisco Meraki MA-ANT-3-D5 - Downtilt Panel Omni Antenna

The Cisco Meraki MA-ANT-3-D5 is a dual-band downtilt panel omnidirectional antenna designed for Meraki MR42E and MR53E access points. Its unique downtilt pattern provides optimized coverage for medium-ceiling environments (8-25 ft), making it ideal for cube office spaces, vestibules, and other medium-density deployments.

🔧 Key Specifications

• Antenna Type: Downtilt panel omnidirectional
• Frequency Range: 2.400-2.500 GHz / 5.150-5.875 GHz
• Gain: 2.4 dBi (2.4 GHz) / 3.7 dBi (5 GHz)
• Polarization: Linear, vertical/horizontal
• Beamwidth (Horizontal): 360°
• Beamwidth (Vertical): 60° centered at ±45° down angle
• Connector: RP-TNC
• Cable: Aliner RG316, 1 m included
• Dimensions: 8.86” x 1.46” (225 mm x 37 mm)
• Weight: 20.11 oz (0.57 kg)
• Material: PC-ABS durable plastic
• Operating Temperature: 0 °C to 40 °C (32 °F to 104 °F)
• Humidity Range: 5% to 93% non-condensing
• Mounting Options: Walls, poles, and ceiling tiles (flush-mount solution included)

🧩 Ideal Use Cases

• Medium-density office deployments (cubicles, open workspaces)
• Vestibules or lobbies requiring consistent downtilt coverage
• Ceiling-mounted AP installations where vertical coverage control is critical
• Environments needing omnidirectional coverage with reduced ceiling reflection
