MS320-24P-HW Preliminary US GPL - Meraki MS320 Cloud Managed 24 P.

Cisco Meraki MS320-24P-HW – Cloud-Managed L3 24-Port Gigabit PoE Switch

The Cisco Meraki MS320-24P-HW is a Layer 3 cloud-managed access switch with 24x 10/100/1000BASE‑T RJ45 ports and 4x 10GbE SFP+ uplinks. It delivers 56 Gbps switching capacity with a 370W PoE budget, making it ideal for powering next-generation APs, VoIP phones, and IP cameras. Managed entirely through the Meraki cloud dashboard, it simplifies deployment, monitoring, and troubleshooting across distributed networks.

🔧 Key Specifications

• Ports:
  • 24x 10/100/1000BASE‑T RJ45
  • 4x 10GbE SFP+ uplinks
• Switching capacity: 56 Gbps non‑blocking fabric
• Forwarding latency: ~2.5 µs
• PoE budget: 370W (802.3af/802.3at PoE+)
• Default PSU: PWR‑MS320‑640WAC
• Optional redundant PSU: PWR‑MS320‑640WAC
• Idle/Full load power: 32W / 454W
• MAC forwarding entries: 32,000
• Form factor: 1RU rack‑mountable
• Dimensions: 19.08 x 17.32 x 1.75 in (48.46 x 44 x 4.44 cm)
• Weight: 8.93 lb (4.05 kg)
• MTBF: ~474,570 hours

🧩 Ideal Use Cases

• Enterprise access: secure, cloud‑managed Layer 3 switching with PoE for APs, phones, and cameras
• Campus edge: scalable deployment with virtual stacking and centralized dashboard management
• Distributed sites: zero‑touch provisioning and remote troubleshooting for branch offices

⚙️ Licensing & Expansion

• Operating mode: Meraki cloud‑managed NX‑OS
• Programmability: centralized dashboard, role‑based administration, scheduled firmware upgrades
• Telemetry: integrated Layer 7 application visibility and per‑port packet capture
• Warranty: lifetime hardware warranty with next‑day advanced replacement
